Convert an image to a different format - PNG, GIF, JPG or BMP
The “Convert Image” action allows the user to change a file from one image format to another.
For example, a user could input a PNG file and convert it into a JPG file using this action.
This is useful as it allows a user to take a file type which may not be compatible with their system and change it to something which is.
Parameters
| Title | Name | Type | Description |
|---|---|---|---|
Format | format | string | Format to convert to |
File | file | file | Reference file |
File (file name) | name | string | New file name |
Response
Status | Title | Name | Type | Description |
|---|---|---|---|---|
Success | Result | result | number | Item count |
Failure | Result | result | string | Error description |
- How to convert an image to a different format in Microsoft Power Automate
- How to convert an image to a different format in Microsoft Power Apps
- How to convert an image to a different format in Salesforce
- How to convert an image to a different format in Nintex
- How to convert an image to a different format with Custom API
How to convert an image to a different format – PNG, GIF, JPG or BMP with Microsoft Power Automate
Instructions
- In the Flow designer, click the “+” icon to insert a new action.
- Select the “Files – Convert Image” action under PowerTools in the “Choose an operation” dialog.
- Insert the necessary values or variables in each input field.
- Execute the flow.
Example
Video
How to convert an image to a different format – PNG, GIF, JPG or BMP with Microsoft Power Apps
Instructions
- Add the PowerTools connector from the Data menu.
- In the formula for the control, variable or element, type “ApptigentPowerTools.ConvertImage().result”. Within the parentheses, enter the field, control or variable that contains the source collection.
- Preview or run the app.
Example
Video
How to convert an image to a different format – PNG, GIF, JPG or BMP with Salesforce
Instructions
- Drag and drop a new action onto the design surface. Edit the action and choose PowerTools from the category menu on the left.
- Click in the “Action” search box, scroll through the action list and choose “Files – Convert Image”. Insert the necessary values or variables in each input field. (Note: Click the “Advanced” link to manually assign output variables to the action results.)
- Run or Debug your flow to preview the results.
Example
Video
How to convert an image to a different format – PNG, GIF, JPG or BMP with Nintex
Instructions
- Locate the “Apptigent PowerTools” group in the actions navigator then drag and drop the “Files – Convert Image” action onto the design surface.
- Insert the necessary values or variables in each input field.
- Assign the result to a variable.
- Test the workflow.
Example
Video
How to convert an image to a different format in another Platform or Custom Code
Instructions
If your platform is not listed and it supports Open API (Swagger) extensions, import the API Definition document from the Developer Edition product on our Customer Portal at https://portal.apptigent.com/product (look for the Open API link at the top of the PowerTools Developer API definition page). Invoke the desired actions in your app or workflow design tool, supplying values for the listed parameters. Refer to the developer documentation on the Customer Portal for details on input and output formats.
If you are developing a custom app, execute a RESTful POST operation to the /CountCollection endpoint in your application code or use the pre-generated client scaffolding from our Github repo at https://github.com/apptigent/powertools. Be sure to include your API Key (Client ID) in the header using the “X-IBM-Client-Id” key/value pair. The body should be a well-formed JSON object with the parameter label(s) and value(s) in the specified format. Refer to the API documentation at https://portal.apptigent.com for more information.
Example
const request = require('request');
const options = {
method: 'POST',
url: 'https://connect.apptigent.com/api/utilities/ConvertImage',
headers: {
'X-IBM-Client-Id': 'REPLACE_THIS_KEY',
'content-type': 'multipart/form-data; boundary=---011000010111000001101001',
accept: 'image/png'
},
formData: {
format: 'JPG',
}
};
request(options, function (error, response, body) {
if (error) throw new Error(error);
console.log(body);
});
